Place of Origin:
China
Brand Name:
RY
Certification:
CE,ROHS
Model Number:
RY-03132
Contact Us
Video
Video
Video
Nickel Plate Bnc Male To L29 Female Gloden Brass Rf Straight Antenna Adapter
Electrical Characteristics:
|
Electric Data |
||
|
Characteristic Impedance |
50ohm | |
|
Frequency Range |
0-11GHz | |
|
Working Voltage |
1000 VRMS(max at sea level) | |
|
Dielectric Withstanding Voltage |
1500 VRMS(min at sea level) | |
| VSWR | Straight: ≤1.3 R/A:≤1.5 |
|
| Contact Resistance | Inner: 1.5 milliohms(max) Outer: 0.2 milliohms(max) |
|
|
Insulation Resistance |
5000 megohms(min) | |
|
Mechanical Data |
||
|
Durability Mating |
500 Cycles min. | |
|
Material Data |
||
|
Connector Parts |
Materials | Plating Finish |
|
Body |
Brass | Nickel or Silver or Sn/Zn/Cu |
|
Male Pin |
Brass | Gold or Sliver |
|
Female Pin |
Beryllium Bronze or Phosphor Bronze | Gold or Sliver |
|
Insulators |
PTFE | N/A |
|
Clamp Gaskets |
Silicone Rubber or Synthetic Rubber | N/A |
|
Crimp Ferrules |
Annealed Copper | Nickel or Silver |
|
Environmental Data |
||
|
Temperature Range |
-65~+165℃ | |
Our this product line features popular coaxial cable, RF connectors, RF cable and other high quality coaxial products such as SMA connectors, coax adapters, and tools.
RF Coaxial cable assemblies are available in 50 Ohm and 75 Ohm styles. In addition, We stocks hundreds of low loss 50 Ohm antenna RF cable assemblies, pigtails and bulk cable for all your wireless connectivity needs.
Product Details:
Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.
2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.
Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.
2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.
3. Fast Delivery Time :2~15 days, On-Time Delivery.
4. Good After-Sales Service: we could offer technical support or return service in short time.
5. 1 Year Warranty.
6. OEM/ODM service.
7. We are available with Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount
FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
2. Can I get samples to test before place an order?
Send your inquiry directly to us
