1616-1626mhz 70×70×14mm Iridium Sbd Magnetic Antenna With Rg174 And Sma Male

Product Details:
Place of Origin: china
Brand Name: RY
Certification: CE,ROHS
Model Number: RY-IR-707014
Payment & Shipping Terms:
Minimum Order Quantity: 20pcs
Price: USD0.88~8.88
Delivery Time: Shipped in 3 days after payment
Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability: 10000pcs

Detail Information

Color:: Black Frequency:: 1616-1626mhz
VSWR:: 1.5 Cable Type:: Rg174
Connector:: SMA Male,etc Type:: Magnetic
High Light:

iridium gps antenna

,

ceramic patch antenna

Product Description



1616-1626mhz 70×70×14mm Iridium Sbd Magnetic Antenna With Rg174 And Sma Male​



Key Specification:



key soecification:



(1)Dielectric Antenna



Center Frequency(MHz):



1616-1626

VSWR:



1:5:1

Bandwidth(MHz):



15min

Impedance(Ω):



50

Dielectric Constant:



8

Peak Gain



>3dBi Based on 7cm×7cm ground plane

Gain Coverage



>-4dBi at –90°<0 <+90°(over 75% Volume)

Polarization:



RHCP

Power Handling (W):



1

(ii)Mechanical



Weight (gram)



<10

Size (mm):



70×70×14

(iii)Environmental



Working Temp:



-40℃~+85℃

Storage Temp:



-45℃~+90℃

Vibration:



Sine sweep 1g(0-p)10~50~10Hz each axis

Humidity:



Humidity95%~100%RH



Product shows:

1616-1626mhz 70×70×14mm Iridium Sbd Magnetic Antenna With Rg174 And Sma Male 0

Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

2. Fast Delivery Time :2~15 days, On-Time Delivery.

3. Good After-Sales Service: we could offer technical support or return service in short time.

4. We are available with Alibaba Trade Assurance, you'll enjoy:
•100% product quality protection
•100% payment protection for your covered amount



FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.



3. What's your delivery time?

If our company have stock, will send to you within one day once receive your fee.

If use customer brands, we will take a 3-5days to prepare materials and mass production.



4. Can your company accept customize?

A: Welcome OEM & ODM

5. What is your terms of delivery?
We are accept EXW, FOB, CIF, etc.
