BNC Male Plug RF Antenna Connector To M5 Type Female Jack Straight TV RF Coaxial Adapter

BNC Male Plug RF Antenna Connector To M5 Type Female Jack Straight TV RF Coaxial Adapter

sma rf connector

rf cable connector

Place of Origin:

China

Brand Name:

RY

Certification:

CE,ROHS

Model Number:

RY-031445

Contact Us

Request A Quote
Product Details
Type:
BNC To M5 Adapter
Application:
RF
Gender:
Male To Female
Plating:
Nickel,gold
Contacts:
Gold-plated Brass Alloy
Samples:
Available
Payment & Shipping Terms
Minimum Order Quantity
20
Price
USD0.88~3.88
Delivery Time
Shipped in 3 days after payment
Payment Terms
L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability
10000pcs
Product Description





BNC Male Plug to M5 type Female Jack Straight TV RF Coaxial Adapter Connector​



Electrical Characteristics:



Freqency Range



DC to 4 GHz

Insertion Loss



≤0.30dB
VSWR ≤1.15


Insulation Resistance



≥5000MΩ

Center Contact Resistance



≤3MΩ

Outer Contact Resistance



≤2MΩ

Mechanical Performance





Mating Cycles



≥500

Environmental Performance





Temperature Range



-55-+165℃

Materials/Finish





Center contact



phosphor bronze , Gold plated

Body



Brass/Nickel plated

Dielectric



PTFE

Other metal parts



Brass/Nickel plated



Adaptor is the basic product that used in the connection between the instrument cables with different interface.These are two kinds of them:within-type adaptor and inter-type adaptor.It has the same technical special characteristic with same class product.Within-type adaptor is listed in the catalogue of that product.Our company designs and produces various adaptors with all kinds of specification.They have wide frequency range and low VSWR characteristics.Welcome to visit and choose.



Product Details:

BNC Male Plug RF Antenna Connector To M5 Type Female Jack Straight TV RF Coaxial Adapter 0

Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:

1. We are professional antenna and cable mamufacturer for 10 years.



2. Our sales manager will reply your inquiry in 24 working hours.



3. Customized design is available, OEM are welcomed.



4. Excellent after-sales service.


5. We are available with Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount



FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. Can you offer samples to test before placing one formal order?
Samples for test purpose can be presented provided and you bear the shipping cost.



3. How long is usually your delivery time?
Our delivery time is usually within 2 weeks after we receive your order.

4. What is our Shipping & Trade terms?

Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.
Delivered time: 2-3 business days for sample, 20-25 days for mass order.
Trade terms: EXW, FOB , CIF etc.
