Internal 1616-1626 MHZ Passive Iridium Satellite Antenna Ceramic Patch Square With 1.13mm Cable Ufl

Product Details:
Place of Origin: china
Brand Name: RY
Certification: CE,ROHS
Model Number: RY-IR-3535
Payment & Shipping Terms:
Minimum Order Quantity: 20pcs
Price: USD0.88~8.88
Delivery Time: Shipped in 3 days after payment
Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability: 10000pcs
Contact Now

Detail Information

Color: Green Frequency: 1616-1626mhz
VSWR: 2 Cable Type: 1.13mm
Connector: UFL Female,etc Type: Whip,puck,panel
High Light:

iridium patch antenna

,

iridium gps antenna

Product Description



Internal Iridium 1616-1626 MHZ Passive Ceramic Patch Square Antenna With 1.13mm Cable Ufl





Key Specification:



( I ) Product Overview



Frequency(MHz):

1616-1626



Impedance(Ω):

50



Peak Gain

>3dBi Based on 7cm×7cm ground plane



Gain Coverage

>-4dBi at –90°<0 <+90°(over 75% Volume)



( II )Mechanical



Weight(gram)

<200



Size(mm):

35*35mm



Cable Length(m):

Optinal



Cable Type:

1.13.1.37,RG178,RG174 etc



Connector:

SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.



( III )Environmental



Working Temp:

-40°C~+85°C



Storage Temp:

-45°C~+100°C



Vibration:

Sine sweep 1g(0-p)10~50~10Hz each axis





Product shows:

Internal 1616-1626 MHZ Passive Iridium Satellite Antenna Ceramic Patch Square With 1.13mm Cable Ufl 0

Internal 1616-1626 MHZ Passive Iridium Satellite Antenna Ceramic Patch Square With 1.13mm Cable Ufl 1

Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

2. Fast Delivery Time :2~15 days, On-Time Delivery.

3. Good After-Sales Service: we could offer technical support or return service in short time.

4. We are available with Trade Assurance, you'll enjoy:
•100% product quality protection
•100% payment protection for your covered amount



FAQ:

1. What is the lead time?(How long do you need me to prepare my goods?)
7 days for sample orders, 7-12 days for mass production orders (based on different quantities, OEM , etc.)



2. How will you deliver goods to me?
We ship by air and sea generally. In the mean time, we cooperate with international expresses such as DHL, UPS, FedEx, TNT to enable our customers to get their goods rapidly.



3. How long do I need to wait before my goods arrive?
9-12 days for air transportation, 7 days for international express.



4. How is your product quality?
Our raw materials are purchased from qualified suppliers. And we have a strong quality control team to guarantee our quality according to standard.



5. What is your warranty?
Our warranty is 12 months after delivery, RY pays high attention to after-sales service.
