1200mbps 4G 5G WiFi Router Single Amplifier Network Booster

Product Details:
Place of Origin: China
Brand Name: RY
Certification: CE,ROHS
Model Number: RY- WG3526
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: USD45~120
Packaging Details: 28*15*6.5cm/Pcs
Delivery Time: Shipped in 7 days after payment
Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram, D/A, D/P
Supply Ability: 100000
Contact Now

Detail Information

Max. LAN Data Rate: 1200Mbps Standards And Protocols: IEEE802.11n/g/b/a/ac
Wi-Fi Supported Frequency: 2.4G & 5G Color: Silver
Supports WPS: Yes Application: ENTERPRISE
LAN Ports: 4 WAN Ports: 1
Product Name: 4G Wifi Router Warranty: 12 Months
Size: 235*165*23mm(LxWxH) Antenna: 2*4g 2*2.4g 2*5.8g
High Light:

1200mbps 4G 5G WiFi Router

,

1200mbps single operational amplifier

,

880Mhz wifi mesh booster

Product Description



4G 1200mbps Long Range Wireless Router Repeater Wifi Single Amplifier Network Booster​



Wireless:
Support IEEE802.11AC/N/G/B/A wireless protocol, max wireless rate could be 1200Mbps , 4×5Dbi high gain antennas , perform better
and cover larger

Software:
The original SDK develop based on the Linux, which is SDK4.2, included the certification of the 802.11AC,IPv6 and Win8. Also
provide the driver of the VPN, audio and the touch screen. The L7 Qos work perfectly with the HNAT/HQos , offer the Auto QoS for
the Internet routers and SMB routers



4G Router Electrical Characteristics:



Specification

Model
1200M Repeater

Size

235*165*23mm
Color

Silver
Type

Wireless Router
Transmission Rate

300mbps
Firewall Function

Support Firewall
Safety Standards

CE
Detachable
YES

Applicable Objects
Mobile phone, computer, etc
Hardware specification
Hardware Specification
Main Chipset
MT7621/Dual Core/880Mhz
RAM
DDR3 RAM 512MB (MAX512MB), DDR2 RAM 256MB
FLASH
SPI FLASH 32MB (MAX64MB)
Protocol Standard
IEEE 802.11ac,IEEE 802.11a
IEEE 802.11n,IEEE 802.11g,IEEE 802.11b;
IEEE 802.3,IEEE 802.3u;
Wireless Rate
5G : 900Mbps
2.4G: 300Mbps
Work Frequency
2.4GHz/5.8GHz
Antenna
4 * 5dBi high gain antenna
Interface
1 10/100M/1000M WAN Port, Auto MDI/MDIX
4 10/100M/1000M LAN Port, Auto MDI/MDIX
1 USB 3.0 port
LED
PWR.SYS.USB.2G.5G.WAN.3.2.1.0
Button
1*RESET
Power consumption
< 12W
Adapter
DC 12V1A
Management
IP:192.168.1.1
USER/PW admin/admin
WAN Type
PPPoE,Dynamic IP,Static IP
Work Mode
AP;
Router;
DHCP
Server, Client, DHCP Client List, Address Reservation
Port Forwarding
Virtual Server, Port Triggering, UPNP, DMZ
Firewall Security
Dos, SPI Firewall
IP Address Filter/MAC Address Filter/ Domain Filter
IP and MAC Address Binding
DDNS
Support
VPN Pass-Through
PPTP, L2TP, IP Sec (ESP Head)
Band Control
Support
Static Router
Support
System Log
Support
Other Function
Mac clone
NTP Synchronize
Web firmware upgrade


How To Choose A 4G Router For Your Business?

There are many 4G routers on the market, offering a wide variety of features. You need to make sure that the router provides functionality and flexibility for your solution needed. Here are the main things to consider when you a compare 4G routers for your business.

Multi-SIM
For speed and reliability in a 4G WAN connection, you’ll need a router that supports more than one cellular connection. This is usually referred to as multi-SIM. Look out for a router that supports this.

SIM Capacity
The performance and throughput of a Multi-SIM router is ultimately limited by the number of simultaneous cellular connections it can support. This is usually referred to by the number of SIMs it can accommodate. However, be aware of the difference between connections and SIMs: a router may allow you to insert two SIMs in case one of them fails, but not be able to use both at the same time. We normally choose a router with the SIM capacity required for your expected usage (eg 6 SIMs). Some routers can be stacked to allow more SIMs (we’ve often used 18 SIMs) in heavy usage scenarios.

Cellular Technology
Most routers today support a version of the 4G standards called Category 4 LTE. Some manufacturers are rolling out support for Category 6 LTE, which uses two chunks of spectrum rather than one, to double the theoretical maximum download speeds from 150 Mbps to 300 Mbps. Cat 6 LTE is still being rolled out by the mobile carriers, so it isn’t available everywhere. However, it’s worth considering routers that support it, in order to future-proof your investment. There are a number of interchangeable terms: look for Cat 6 LTE, LTE-Advanced (aka LTE-A) and 4G+.

Bonding
A router that can bond (ie combine) the traffic streams from multiple SIMs into one, will allow you to have a faster, more reliable connection to your company network. This is essential if you’re planning to connect a multi-user site to your company network using 4G WAN, and especially if you need a very reliable connection for sensitive applications (see Managed Hubs). The rationale for bonding is primarily to provide a reliable and stable connection, with performance as a by-product.

Load Balancing
Alternatively, a router that can Load Balance can spread the usage of several separate users and sessions across several SIMs. This can provide flexibility, but no single session can be faster than the SIM its using can support, and if any single cellular connection drops out, the reconnection time can be measured in seconds, which the user will notice! Find out more here in our blog: 4G WAN Bonding vs Load balancing.

SIM Failover
Typically found in single-connection routers, SIM failover allows two SIMs to be inserted, so that the second can be switched-in if the first fails (or if the first is blocked when usage climbs too high).

Prioritisation by traffic type
Some routers can be set to optimise the performance of your 4G WAN connection. They might prioritise (and de-prioritise) different traffic types. They might route those traffic types over different cellular connections according to the real-time performance of the connections (eg latency and reliability of the connection). If you have performance sensitive applications, or if you are delivering traffic using performance sensitive applications like Citrix, you will need these features for optimum results. This is only really relevant when bonding, because bonding allows you to control priority in both directions, both to and from the site. If you load balance on multi-sim, you can only control priority in one direction (outbound) – you cannot influence the inbound priority.

Caching
Some routers will allow you to cache data. When multiple users access the same intranet pages or stored files, for example, caching allows them to access it faster and with less data usage.

Other WAN interfaces
Some routers will allow you to connect an additional WAN circuit that can be used alongside the cellular connections. The rationale would be to allow the use, where available, of a connection that is faster, cheaper or has more capacity than the cellular connections. The additional connection might be a DSL, EFM or satellite circuit, or perhaps the ability to connect into a WiFi hotspot. It might be implemented as an Ethernet port, or perhaps a dedicated DSL port.

WiFi
Some 4G routers provide WiFi, access for users, reducing the need for additional equipment in small installations. Some will provide isolated guest access. Some will provide private corporate access as well a public guest access via a captive portal to enable you to force guests to provide details about themselves.

WiFi controller
Some routers can act as the WiFi controller for a number of WiFi access points, simplifying WiFi deployment and extending the coverage in larger installations.

Modular Design
Some router manufacturers use fixed router configurations, keeping the deployment as simple as possible. Others employ a modular design in which cards are inserted for the particular application. For example, two 4G cards might be installed on one occasion and a 4G card plus a DSL card on another. This can be helpful if you envisage re-using the device in different locations. It can also allow you to install with 4G and then later to migrate seamlessly to a fixed circuit (eg DSL or EFM) once that is installed. This is particularly useful if you need to install rapidly and/or if you would like to retain the 4G card for backup once a fixed circuit is installed. See our Rapid Site Deployment for a next day infrastructure delivery.

Power over Ethernet (POE)
Some 4G routers can provide Power over Ethernet, to devices that are plugged into their Ethernet ports. This allows you to provide power to Wireless Access Points or IP phones without having to buy separate power over ethernet switches or power injectors.

Reporting
Some devices provide detailed reporting on cellular usage, including information on which devices are driving the usage. This can be very helpful in managing costs.

What Hardware do we use?
Having explored the features to compare in a 4G WAN router, an obvious question is: “ What is the best 4G router for business use?” We have built up a lot of experience from deploying 4G WAN technology to hundreds and hundreds of sites. Over the years we have settled on one manufacturer for the majority of our installations: Peplink.



4G Router Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies
optical fibers cable and antennas router repeater in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.



3. Quality is important for us and for the customer, the client’s demand is more supreme. We create an easier, less costly and extremely satisfactory way of business. Striving to achieve improving results through our continuous innovating and technical engineer’s effort, we create values to turn the antenna / Cable / Harness to your exact demand.


4. We guarantee every antenna / Cable / Harness we offered must be tested by network analyzer / Precision Low Voltage Wire Tester to ensure the perfect quality before delivery. Cooperated with many overseas clients from over twenty countries, we will be your ideal OEM/ODM partner.



4G Router Product Details:

1200mbps 4G 5G WiFi Router Single Amplifier Network Booster 0

1200mbps 4G 5G WiFi Router Single Amplifier Network Booster 1

1200mbps 4G 5G WiFi Router Single Amplifier Network Booster 2

1200mbps 4G 5G WiFi Router Single Amplifier Network Booster 3
FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. Do you have stock?
 We don’t have stock; we’ll start production after receiving PO.

3.What's information do you need for quoting?
For Cable harness, please advise cable specs, part number, or send drawings.
For Connectors, please kindly advise series pins, male or female, molded, field assembly panel mount type and cable length.

4. What's your payment terms?
100 % T/T before delivery

5. What is your terms of delivery?
We are accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or most cost-effective for you.
