Place of Origin:
China
Brand Name:
RY
Certification:
rohs
Model Number:
RY-CAT6-RJ45-20
Contact Us
Video
| Specification | |
| Cable Spec | CAT6 32AWG 4pairs+AEB |
| Cable Length | 6ft, 10ft, 15ft, 25ft, 50ft, (Custom Length available) |
| Color | Black, Beige ,Blue(Custom Color available) |
| Diameter | OD:1.9*7.0mm |
| Wire Gauge | 32AWG,30AWG |
| Conductor | bare copper(BC),Tin plated copper(TC)(optional) |
| Certificate | RoHS,UL,CE,FCC |
| Plug mould | PVC molding, plastic shell , metal shell |
| Connector | gold-plated |
| Electrical Properties | |
| Quality Control | 100% open & short test |
| Voltage | DC300V 5M ohm/10ms |
| Insulation Resistance | 10M min |
| Contact Resistance | 2 ohm max |
| Working Temperature | -25C-80C |
| Data transfer rate | 10.2Gbps Max |
| Differential Impedance | 100±10Ω(TDR) |
| Complies with | TIA/EIA 568B standard |
Super six type cabling system refers to the transmission bandwidth up to 500MHz, transmission of 10Gbps Ethernet cabling system. The conductor is 23AWG oxygen - free copper wire.
Twisted-pair six type of cable is eight core structure, also increased the visible to the naked eye to cross the skeleton of the insulation, four pairs of twisted pair can be isolated, and along with the change of the length of the rotation Angle, maintain the relative position of four sets of twisted pair, reduce transmission signal crosstalk in the process and return loss, but also more thick, the diameter of the six class line signal transmission speed faster, Transmission frequency is up to 250MHz!
