2.4 5.8GHz Dual Band IP67 Outdoor WIFI Antenna Anti - UV Grey Whip With N

Product Details:
Place of Origin: China
Brand Name: RY
Certification: CE,ROHS
Model Number: RY-WIFI-6457913
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: USD2.88~8.88
Delivery Time: Shipped in 3 days after payment
Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability: 10000pcs
Contact Now

Detail Information

Color: Grey Mounting Type: Embedded,Screw,adhesive,magnetic
Application: Indoor/Outdoor Gain: 5Dbi
Connector: N Male Type: Whip,puck,panel
High Light:

dual band wifi antenna outdoor

,

dual wifi antenna

Product Description


wifi 2.4 5.8GHz Dual band IP67 Anti-UV grey whip Antenna with N for Outdoor indoor





Key Specification:



Electrical Specifications

Frequency range(MHz)

2400-2483/4850-4950/5200-5300/5725-5850



Gain(dBi)

5



VSWR
≤2

Input Impedance(Ω)
50

Return Loss(dbi)

17



Maximum input power(W)

50



Radome material
plastic

Polarization

Vertical



Radome Color

grey



Mechanical Specifications

Antenna size-mm

180



Antenna weight(kg)
0.043

Operating temperature(°c)
-40~60

Storage Tem(℃)

-45~100℃



Rated Wind Velocity(m/s)
60

Radome color
silver

Waterproof Standard
IP54/ IP65/ IP67

Mounting way

Direct




Product Details:

2.4 5.8GHz Dual Band IP67 Outdoor WIFI Antenna Anti - UV Grey Whip With N 0

2.4 5.8GHz Dual Band IP67 Outdoor WIFI Antenna Anti - UV Grey Whip With N 1

2.4 5.8GHz Dual Band IP67 Outdoor WIFI Antenna Anti - UV Grey Whip With N 2

Download Drawing Here:



RY-2.4 5.8GHZ.pdf



Our Company:


1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our Advantages:


1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

3. Good After-Sales Service: we could offer technical support or return service in short time.

4. 1 Year Warranty.

5. OEM/ODM service.

6. We are available with Trade Assurance, you'll enjoy:
•100% on-time shipment protection
•100% payment protection for your covered amount



Application:



1. The antenna radiates and receives radio waves. However, it is not radio waves that the transmitter sends to the antenna through the feeder. The receiving antenna can not send radio waves directly through the feeder to the receiver, which must go through the energy conversion process. Next, we take the radio communication equipment as an example to analyze the signal transmission process, and then explain the energy conversion function of the antenna.



2. At the transmitter end, the modulated high frequency oscillating current (energy) generated by the transmitter is fed into the transmitting antenna by the feeding device (the feeding device can transmit current wave or electromagnetic wave directly depending on the frequency and form). The transmitting antenna converts the high frequency current or guided wave (energy) into radio wave-free electromagnetic wave (energy) to the circumference. Circumferential radiation (see Figure 1); at the receiving end, radio waves (energy) are converted into high-frequency current or guided waves (energy) through the receiving antenna and transmitted to the receiver via the feeding device. From the above process, it can be seen that the antenna is not only a device for radiating and receiving radio waves, but also an energy converter and an interface device between circuit and space.



FAQ:


1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.



3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

4. What is your terms of delivery?
We are accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or most cost-effective for you.
