Bnc Female With Waterproof Ring And Nut Fixed To Bnc Female Rf Adapter Connector

Product Details:
Place of Origin: China
Brand Name: RY
Certification: CE,ROHS
Model Number: RY-8259
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: USD0.88~3.88/PC
Delivery Time: Shipped in 3 days after payment
Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability: 10000pcs
Contact Now

Detail Information

Type:: BNC Application:: RF
Gender:: Male To Female Dielectric:: PTFE
Freqency Range:: DC To 3GHz Temperature:: -55-+155℃
High Light:

sma rf connector

,

rf cable connector

Product Description



Bnc Female With Waterproof Ring And Nut Fixed To Bnc Female Rf Adapter Connector​



Electrical Characteristics:



Temperature Range



  -55~+155℃(PE Cable -40~+85)

Vibration



  100m/S2 (10-500Hz), 10g

Impedance



  50 Ω, 75Ω

Frequency Range



  DC -4GHz

Working Voltage



  500V r.m.s at sea level

Withstanding Voltage



  1500V r.m.s at sea level
Contact Resistance Center contact ≤1.5m Ω
  Outer contact ≤1m Ω

Contact Pin



  Brass-Au / Ag plated

Insulation resistance



  ≥5000M Ω
Center Conductor Retention Force   ≥0.57N
Voltage Standing Wave Ratio Straight ≤ 1.22/3GHZ
  Right angle ≤ 1.30/3GZ

Durability(mating)



  ≤500cycles

Body



  Brass--Ni plated

Contact



  Beryllium copper

Insulator



  PTFE
  • RF coaxial cable assembly (7/16 DIN/N/TNC/BNC/FME/U.FL/IPEX/L9/SMA/SMB/MMCX/MCX/OEM)
  • We focus on coaxial assemblies
  • Our custom RF cable assemblies are built-in and shipped worldwide
  • RF cable assemblies in 50 ohms can be ordered using the following connector types such as 7/16 DIN, BNC, FME, MCX, MMCX, N, QMA, SMA, SMB, SMC, SMP, SSMB, TNC, UHF, U.FL and 75 ohms cable assemblies can be made with the following 75 ohms connectors such as BNC, F, N, SMB, SMC, TNC and mini SMB
  • RF cable assemblies includes: RG141/RG142/RG174/ RG178/RG179/RG180/ RG187/RG196/RG213/RG214/RG218/RG219/ RG223/RG303/RG316/RG316-DS/RG393/RG400/RG401/RG402/RG405/RG58/U
  • RF cable assemblies can be produced with many different connector types and custom lengths depending on your needs and applications
  • If you require a special RF cable assembly configuration not found here, you can create your own RF cable assembly configuration by calling our sales department
  • Power person who join in the what series of N products join by one whorl, it has the characteristic of reliable and strong ant-vibration nature, machinery and electric performance finely. It is used in vibration and environment abominable radio equipment of terms and instrument and ground launch system join the coaxial cable of the radio frequency extensively.



Product Details:

Bnc Female With Waterproof Ring And Nut Fixed To Bnc Female Rf Adapter Connector 0

Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

3. Fast Delivery Time :2~15 days, On-Time Delivery.

4. Good After-Sales Service: we could offer technical support or return service in short time.

5. 1 Year Warranty.

6. OEM/ODM service.

7. We are available with Alibaba Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount


FAQ:

1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. Can I get samples to test before place an order?

Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

4. What is our Shipping & Trade terms?

Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.
Delivered time: 2-3 business days for sample, 20-25 days for mass order.
Trade terms: EXW, FOB , CIF etc.
