Straight Bnc Male To Bnc Male Coaxial Rf Metal Material Male Adapter

Product Details:
Place of Origin: China
Brand Name: RY
Certification: CE,ROHS
Model Number: RY-03135
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: USD0.88~3.88
Delivery Time: Shipped in 3 days after payment
Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability: 10000pcs
Contact Now

Detail Information

Type:: Bnc To Bnc Adapter Application:: RF
Gender:: Male To Male Plating:: Nickel,gold
Contacts:: Gold-plated Brass Alloy Samples:: Available
High Light:

sma rf connector

,

rf cable connector

Product Description



Straight Bnc Male To Bnc Male Coaxial Rf Metal Material Male Adapter



Electrical Characteristics:



Electrical performance



Characteristic impedance:



50Ω

Rated current:



0~18GHz
Contact resistance:

inner conductor≤3mΩ

outside conductor≤2mΩ

Dielectrically withstanding voltage:



1000VRMS

Voltage rating:



335 VRMS

Insulation Resistance:



≥ 5000MΩ

Mechanical performance



Inner conductor separating force:



≥0.28N

Durability:



500 times

Material and surface treatment:



metal material, workmanship and surface treatment

Contact



Material of male:



copper alloy

Surface treatment:



full copper and silver-plated

Workmanship:



machining operation

Material:



copper alloy

Surface Treatment:



full copper and silver-plated

Workmanship:



machining operation Plastic, workmanship andforming

Insulator



Material:



polytetrafluoroethylene

Workmanship:



machining operation

Operation environment



Temperature Range:



-55℃~+155℃

Shock:



500 m/s2

Vibration:



10~2000Hz,10m/s2

Structure and Dimension



Maximum dimension of plug:



Customized



Our this product line features popular coaxial cable, RF connectors, RF cable and other high quality coaxial products such as SMA connectors, coax adapters, and tools.


RF Coaxial cable assemblies are available in 50 Ohm and 75 Ohm styles. In addition, We stocks hundreds of low loss 50 Ohm antenna RF cable assemblies, pigtails and bulk cable for all your wireless connectivity needs.
Coax interfaces include: BNC, SMA, TNC, Type F, RCA, SMB, MCX, MMCX, Type-N, and more. We carry coax RF connectors and tools such as cable strippers, coaxial crimp tools, compression tools, and pin crimp tools to accommodate all of your coaxial termination requirements.



Product Details:

Straight Bnc Male To Bnc Male Coaxial Rf Metal Material Male Adapter 0

Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

3. Fast Delivery Time :2~15 days, On-Time Delivery.

4. Good After-Sales Service: we could offer technical support or return service in short time.

5. 1 Year Warranty.

6. OEM/ODM service.

7. We are available with Alibaba Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount




FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. Can I get samples to test before place an order?

Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

4. Can you do the design for us?
Yes. We have a professional engineer having rich experience in wire harness & cable assembly design. Just let us know your ideas and we will help to carry out your ideas into perfect products. It does not matter if you do not have someone to complete files. Tell us your detalied SPEC. of products, and we will send you finished drawing for confirmation.

5. What is our Shipping & Trade terms?

Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.
Delivered time: 2-3 business days for sample, 20-25 days for mass order.
Trade terms: EXW, FOB , CIF etc.
