Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black

Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black

    • Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black
    • Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black
  • Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black

    Product Details:

    Place of Origin: China
    Brand Name: RY
    Certification: CE,ROHS
    Model Number: RY-gps-83664

    Payment & Shipping Terms:

    Minimum Order Quantity: 20
    Price: USD0.88~5.88
    Delivery Time: Shipped in 3 days after payment
    Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
    Supply Ability: 10000pcs
    Contact Now
    Detailed Product Description
    Color:: Black Mounting Type:: Embedded,Screw,adhesive,magnetic
    Application:: Indoor/Outdoor Cable Type:: RG174
    Connector:: SMA Type:: Whip,puck,panel

    Outdoor Waterproof Patch Active Car External GPS Magnet Mount Antenna Sma Male​



    Specification

    Center frequency range 1575.42MHz ± 3MHz
    VSWR 1.5:1
    Impedance 50Ω
    Polarization type RHCP
    Peak gain >3dBic based on 7 x 7cm ground plane
    Gain coverage >-4dbic at -90<0<+90 (over 75%volume)


    LNA/filter:

    LNA gain (without cable) 32dB typical
    Noise figure 1.5dB

    Filter out band attenuation

    (f0 = 1575.42MHz)

    7dB minimum: f0 20MHz
    20dB minimum: f0 50MHz
    30dB minimum: f0 100MHz
    VSWR <2.0
    DC voltage 3.0 to 5.0V/other
    DC current 5/10mAh maximum


    Mechanical:

    Weight <200g
    Size(mm) 48*39
    Cable RG174 5 or 3m
    Connectors SMA, SMB, SMC, MCX, and MMCX, or others


    Environmental:

    Working Temp -40'C~+85'C
    Storage Temp -45'C~+100'C
    Vibration Sine sweep 1g(0-p)10~50~10Hz each axis
    Humidity 95%~100%RH
    Weatherproof 100%



    Product Details:

    Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black

    Antenna Size:

    Outdoor Car External Gps Magnet Mount Antenna Waterproof Sma Male In Black

    Our Company:

    1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

    2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

    Our advantages:
    1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

    2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

    3. Fast Delivery Time :2~15 days, On-Time Delivery.

    4. Good After-Sales Service: we could offer technical support or return service in short time.

    5. 1 Year Warranty.

    6. OEM/ODM service.

    7. We are available with Alibaba Trade Assurance, you'll enjoy:
    •100% product quality protection
    •100% on-time shipment protection
    •100% payment protection for your covered amount




    FAQ:
    1. When can I ?
    We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

    2. How can I get a sample to check your quality?
    After price confirmation, you can require for samples to check our quality.



    3. How long can I expect to get the sample?
    After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

    4. Can you do the design for us?
    Yes. We have a professional engineer having rich experience in wire harness & cable assembly design. Just let us know your ideas and we will help to carry out your ideas into perfect products. It does not matter if you do not have someone to complete files. Tell us your detalied SPEC. of products, and we will send you finished drawing for confirmation.

    5. What about the lead time for mass production?
    Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to15 days. Generally speaking, all of the goods can be reach your address within 4 weeks.

    6. What is your terms of delivery?
    We are accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or most cost-effective for you.
