N Male Plug To Bnc Female Jack Straight Audio Rf Coaxial Adapter Connector
Electrical Characteristics:
|
Temperature Range
|
-55~+155°C(PE Cable -40~+85°C) |
|
Vibration
|
100m/S²(10~500Hz)10g |
|
Impedance
|
50Ω |
|
Frequency Range
|
DC~11GHz |
|
Working Voltage
|
1000V r.m.s at sea level |
|
Withstanding Voltage
|
2500V r.m.s at sea level |
| Contact resistance |
Center Contact ≤1mΩ Outer Contact ≤1mΩ |
|
Insulation resistance
|
≥5000MΩ |
|
Center conductor retention force
|
≥0.56N |
|
Coupling nut retention force
|
≤450N |
|
Insertion Loss
|
≤0.24dB/6GHz |
| Voltage Standing Wave Ratio |
Straight ≤1.15+6GHz Right angle ≤1.25+6GHz
|
|
Durability(mating)
|
≥500times(cycles) |
Our this product line features popular coaxial cable, RF connectors, RF cable and other high quality coaxial products such as SMA connectors, coax adapters, and tools.
RF Coaxial cable assemblies are available in 50 Ohm and 75 Ohm styles. In addition, We stocks hundreds of low loss 50 Ohm antenna RF cable assemblies, pigtails and bulk cable for all your wireless connectivity needs.
Coax interfaces include: BNC, SMA, TNC, Type F, RCA, SMB, MCX, MMCX, Type-N, and more. We carry coax RF connectors and tools such as cable strippers, coaxial crimp tools, compression tools, and pin crimp tools to accommodate all of your coaxial termination requirements.
Product Details:
Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.
2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.
Our advantages:
1. We are professional antenna and cable mamufacturer for 10 years.
2. Our sales manager will reply your inquiry in 24 working hours.
3. Customized design is available, OEM are welcomed.
4. Excellent after-sales service.
5. We are available with Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount
FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
2. Can I get samples to test before place an order?
3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.
4. What is our Shipping & Trade terms?
