Place of Origin:
China
Brand Name:
RY
Certification:
CE,ROHS
Model Number:
RY-03150
Contact Us
BNC Female To BNC Female Connector Bulkhead Metal Material Female Straight Adapter
Electrical Characteristics:
Product Specification
|
|
Nominal Impedance
|
50Ω |
Freqency Range
|
DC to 3GHz |
Insertion Loss
|
≤0.40dB |
VSWR
|
≤1.2(DC 3GHz) |
Insulation Resistance
|
≥1000MΩ |
Center Contact Resistance
|
≤6mΩ |
Ourter Contact Resistance
|
≤4mΩ |
Mechanical
|
|
Mating Cycles
|
≥500 |
Environmental
|
|
Temperature Range
|
-55~+155℃ |
Materials/Finish
|
|
Center Conductor
|
Beryllium bronze/Gold plated |
Body
|
Brass/Gold plated |
Dielectric
|
PTFE |
Product Details:
RY offers a full range of pre-assembled, fixed length, standard cable assemblies. Standard assemblies are for use in a variety of commercial and industrial applications that require standard configurations or lengths. Cables are available with most commercially available RF connector series mounted to popular flexible cables as well as semi-rigid conformable (hand formable) cable. Custom assemblies are also available.
Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.
2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.
Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.
2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.
3. Fast Delivery Time :2~15 days, On-Time Delivery.
4. Good After-Sales Service: we could offer technical support or return service in short time.
5. 1 Year Warranty.
6. OEM/ODM service.
7. We are available with Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount
FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
2. Can I get samples to test before place an order?
3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.
4. Can you do the design for us?
Yes. We have a professional engineer having rich experience in wire harness & cable assembly design. Just let us know your ideas and we will help to carry out your ideas into perfect products. It does not matter if you do not have someone to complete files. Tell us your detalied SPEC. of products, and we will send you finished drawing for confirmation.
5. What is our Shipping & Trade terms?
