Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter

Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter

    • Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter
    • Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter
    • Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter
    • Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter
  • Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter

    Product Details:

    Place of Origin: China
    Brand Name: RY
    Certification: CE,ROHS
    Model Number: RY-03151

    Payment & Shipping Terms:

    Minimum Order Quantity: 20
    Price: USD0.88~3.88/PC
    Delivery Time: Shipped in 3 days after payment
    Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
    Supply Ability: 10000pcs
    Contact Now
    Detailed Product Description
    Type: BNC To BNC Application: RF
    Gender: Female To Female Dielectric: PTFE
    Freqency Range: DC To 4GHz Temperature: -55-+155℃





    Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter​r​





    Electrical Characteristics:



    Electrical





    Characteristic Impedance



    50ohm

    Frequency Range



    DC-4GHz

    VSWR



    ≤1.30@DC-1000MHz

    Insertion Losss



    ≤0.2dB

    3rd Order IM (PIM3)



    Working Vlotage



    500V RMS,50Hz,at sea level

    Dielectric Withstanding Voltage



    ≥1500V RMS,50Hz,at sea level

    Dielectric Resistance



    ≥5000MΩ

    Contact Resistance



    Center Contact ≤1.5mΩ

    Mating



    Mechanical





    Durability



    Mating cycles ≥500

    Operating Temperature



    _45 ℃~-85 ℃

    Weatherproof Rate



    IP67

    RoHs (2002/95/EC)



    Compliant by exemption

    Suitable Cable Family





    RF cable Description:



    • 50 Ω and 75 Ω impedance designs allow customers to match impedance to system requirements
    • 50 Ω and 75 Ω connectors are intermateable to ensure non-destructive mating
    • Three grades of connectors are available for military, industrial and commercial applications

    Application:

    - WiFi Antenna
    - Signal Booster
    - Repeaters
    - Radio
    - RF coaxial coax
    - Extension cable
    - FPV Drone



    Product Details:

    Normal BNC Male Connector To Three Way Coaxial BNC Female RF Coaxial Adapter

    Our Company:
    1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

    2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

    Our advantages:
    1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

    2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

    3. Fast Delivery Time :2~15 days, On-Time Delivery.

    4. Good After-Sales Service: we could offer technical support or return service in short time.

    5. 1 Year Warranty.

    6. OEM/ODM service.

    FAQ:

    1. When can I ?
    We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

    2. Can I get samples to test before place an order?

    Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



    3. How long can I expect to get the sample?
    After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.



    4. What's your payment term?

    We usually accept PAYPAL,T/T as the main payment term.



    5. What is our Shipping ?

    Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.
