O Ring 50 Ohm 11mm Screw Connector Bulkhead Waterproof SMA Female Jack

O Ring 50 Ohm 11mm Screw Connector Bulkhead Waterproof SMA Female Jack

Bulkhead Waterproof Screw Connector

11mm Screw Connector

SMA Female Jack Screw Connector

Place of Origin:

China

Brand Name:

RY

Certification:

CE,ROHS

Model Number:

RY-2871356

Contact Us

Request A Quote
Product Details
Type:
SMA
Application:
RF
Gender:
Male To Female
Dielectric:
PTFE
Freqency Range:
DC To 6GHz
Temperature:
-55-+155℃
Payment & Shipping Terms
Minimum Order Quantity
100
Price
USD0.88~2.88
Packaging Details
40*40*30cm...etc
Delivery Time
Shipped in 3 days after payment
Payment Terms
L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability
10000pcs
Product Description



O Ring 50 ohm Bulkhead Waterproof SMA Female Jack 11mm Screw Connector For Rg316 Cable


Electrical Characteristics:


SMA, a common antenna interface:

SMA is the abbreviation of Sub-Miniature-A. The full name of the SMA antenna interface should be SMA reverse male head, that is, the antenna connector is internally threaded and the inner contact is a needle (one end of the wireless device is externally threaded and the inner contact is a tube). ). Wireless devices with this interface are the most popular. More than 70[%] APs, wireless routers, and wireless network cards with more than 90[%] PCI interfaces use this interface. Quite a few are of this type, but the needles and tubes inside are the opposite of wireless devices. Wireless APs and wireless routers using this interface include most of the civilian equipment. TP-LINK, DLINK, Netgear, Belkin and other brands basically use this interface as long as the antenna is detachable. The antenna interface of SMA should be SMA, and SMA and RP-SMA are different. There are many types of SMA. The difference in polarity is called "SMA" and the other is called "RP-SMA". The difference between them is: the standard SMA is: "external thread + hole", "internal thread + needle" ", RP-SMA is: "external thread + needle", "internal thread + hole".



Interface
EC 60169-15
Characteristic Impedance
50ohm
Frequency Range
DC-12GHz
Insertion Loss
≤0.10dB
VSWR
≤1.15@DC-3000MHz
Durability
Mating cycles ≥500
Parts Name
Material
Plating
Body
Brass
AU/NI
Insulator
PTFE
-
Center Conductor
Phosphor Bronze
-
Coupling Nut
Brass
AU
Gasket
Silicone Rubber
AU
Operating Temperature
-40°C-85 °C
Weatherproof Rate
IP67


Product Details:

O Ring 50 Ohm 11mm Screw Connector Bulkhead Waterproof SMA Female Jack 0
Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.
2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.


Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.
2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.
3. Fast Delivery Time :2~15 days, On-Time Delivery.
4. Good After-Sales Service: we could offer technical support or return service in short time.
5. 1 Year Warranty.
6.  you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount


FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.



2. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.

3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

4. What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to15 days. Generally speaking, all of the goods can be reach your address within 4 weeks.



5. What is your terms of delivery?
We are accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or most cost-effective for you.
