Nickel Plating Connector 50ohm Tnc Female Jack To Bnc Male Plug Straight Rf Adapter

Nickel Plating Connector 50ohm Tnc Female Jack To Bnc Male Plug Straight Rf Adapter

sma rf connector

rf cable connector

Place of Origin:

China

Brand Name:

RY

Certification:

CE,ROHS

Model Number:

RY-8832

Contact Us

Request A Quote
Product Details
Type:
BNC To TNC
Application:
RF
Gender:
Female
Dielectric:
PTFE
Freqency Range:
DC To 7.5GHz
Temperature:
-55-+155℃
Payment & Shipping Terms
Minimum Order Quantity
20
Price
USD0.88~5.88
Delivery Time
Shipped in 3 days after payment
Payment Terms
L/C, T/T,Paypal, Western Union, MoneyGram
Supply Ability
10000pcs
Product Description



Nickel Plating Connector 50ohm Tnc Female Jack To Bnc Male Plug Straight Rf Adapter​





Electrical Characteristics:



Temperature Range



  -55~+155℃(PE Cable -40~+85)

Vibration



  100m/S2 (10-500Hz), 10g

Impedance



  50 Ω, 75Ω

Frequency Range



  DC -4GHz

Working Voltage



  500V r.m.s at sea level

Withstanding Voltage



  1500V r.m.s at sea level
Contact Resistance Center contact ≤1.5m Ω
  Outer contact ≤1m Ω

Contact Pin



  Brass-Au / Ag plated

Insulation resistance



  ≥5000M Ω
Center Conductor Retention Force   ≥0.57N
Voltage Standing Wave Ratio Straight ≤ 1.22/3GHZ
  Right angle ≤ 1.30/3GZ

Durability(mating)



  ≤500cycles

Body



  Brass--Ni plated

Contact



  Beryllium copper

Insulator



  PTFE


Product Details:

Nickel Plating Connector 50ohm Tnc Female Jack To Bnc Male Plug Straight Rf Adapter 0

Our Company:
1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

Our advantages:
1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

3. Fast Delivery Time :2~15 days, On-Time Delivery.

4. Good After-Sales Service: we could offer technical support or return service in short time.

5. 1 Year Warranty.

6. OEM/ODM service.

7. We are available with Trade Assurance, you'll enjoy:
•100% product quality protection
•100% on-time shipment protection
•100% payment protection for your covered amount




FAQ:
1. When can I ?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2. How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality.



3. How long can I expect to get the sample?
After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

4. Can you do the design for us?
Yes. We have a professional engineer having rich experience in wire harness & cable assembly design. Just let us know your ideas and we will help to carry out your ideas into perfect products. It does not matter if you do not have someone to complete files. Tell us your detalied SPEC. of products, and we will send you finished drawing for confirmation.

5. What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to15 days. Generally speaking, all of the goods can be reach your address within 4 weeks.

6. What is your terms of delivery?
We are accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or most cost-effective for you.
