7 / 16 DIN Male To N Rf Antenna Adapter Female DMNF - NFDM Base Station Project

7 / 16 DIN Male To N Rf Antenna Adapter Female DMNF - NFDM Base Station Project

    • 7 / 16 DIN Male To N Rf Antenna Adapter Female DMNF - NFDM Base Station Project
    • 7 / 16 DIN Male To N Rf Antenna Adapter Female DMNF - NFDM Base Station Project
  • 7 / 16 DIN Male To N Rf Antenna Adapter Female DMNF - NFDM Base Station Project

    Product Details:

    Place of Origin: China
    Brand Name: RY
    Certification: CE,ROHS
    Model Number: RY-03154

    Payment & Shipping Terms:

    Minimum Order Quantity: 20
    Price: USD0.88~5.88
    Delivery Time: Shipped in 3 days after payment
    Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
    Supply Ability: 10000pcs
    Contact Now
    Detailed Product Description
    Type: DIN To N Application: RF
    Gender: Male To Female Plating: Nickel,gold
    Contacts: Gold-plated Brass Alloy Samples: Available



    7 / 16 DIN Male To N Female DMNF-NFDM The Base Station Project RF Adapter​





    Electrical Characteristics:



    Electrical Performance



    Impedance



    50 Ohms

    Frequency Range



    DC-7.5GHz

    Voltage Rating



    500V

    Dielectric Withstanding Voltage



    1500V

    VSWR

    Straight:

    Right-Angle:



    1.25@6GHz Max.

    1.3@6GHz Max.

    Contact Resistance

    Center contact:

    Outer contact:



    1.50m Ohms Max.

    1.00m Ohms Max.

    Insulation Resistance



    5000Mohms

    Insertion Loss



    0.24dB @ 3GHz Max.

    RF Leakage



    /

    Material Specifications



    Bodies



    Nickel-plated Brass

    Pin Contact



    Gold-plated Brass

    Socket Contact



    Gold-plated Beryllium copper

    Insulator



    PTFE(Telfon)

    gasket



    Silicone Rubber

    Crimp Ferrule



    Copper alloy

    Durability



    500matings

    Environmental Date



    Temperature Range



    -55~+155

    Thermal Shock



    MIL-STD-202 methord

    Vibration



    100m/s, 10g

    Water Proof



    Heat shrink tube or Silicone Rubber Gasket

    Corrosion



    5% salt-solution 48Hours Min.

    IP



    67

    Other Specifictions



    Standard Applicable



    MIL-C-39012; CECC 22210; IEC60169-16;

    RoHS



    Compliant































































































































    Product Details:

    7 / 16 DIN Male To N Rf Antenna Adapter Female DMNF - NFDM Base Station Project

    Our Company:
    1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

    2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

    Our advantages:
    1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

    2. Fast Delivery Time :2~15 days, On-Time Delivery.

    3. Good After-Sales Service: we could offer technical support or return service in short time.

    4. 1 Year Warranty.

    5. OEM/ODM service.

    6. 100% payment protection for your covered amount


    FAQ:
    1. When can I ?
    We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.



    2. What is the MOQ?

    Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.



    3. Can I get samples to test before place an order?

    Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



    4. How long can I expect to get the sample?
    After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.

    5. What is our Shipping & Trade terms?

    Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.
    Delivered time: 2-3 business days for sample, 20-25 days for mass order.
    Trade terms: EXW, FOB , CIF etc.
