Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable

Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable

    • Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable
    • Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable
    • Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable
    • Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable
  • Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable

    Product Details:

    Place of Origin: China
    Brand Name: RY
    Certification: CE,ROHS
    Model Number: RY-40254

    Payment & Shipping Terms:

    Minimum Order Quantity: 20
    Price: USD0.88~4.88
    Delivery Time: Shipped in 3 days after payment
    Payment Terms: L/C, T/T,Paypal, Western Union, MoneyGram
    Supply Ability: 10000pcs
    Contact Now
    Detailed Product Description
    Brand Name:: RY Pin: 40pin
    Application:: Electronic Connector:: FC-40
    Housing:: FC-40 Pitch:: 2.54mm
    Length:: Customized Samples:: Available





    Double Row Fc-40 2.54mm 40pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable





    Electrical Characteristics



    Product name: flat ribbon cable
    Pitch: 1.27mm
    pin: 40 pin
    Length: Custom
    Color: rainbow
    Wire guage: UL2651 28AWG
    Material: Tinned copper
    Conductor: 7*0.127TS
    Thickness: 0.95mm
    Width: 40*1.27mm
    Rated working voltage: 300V
    Rated operating temperature: 105 ℃
    Application: Signal transmission
    Connector: 2.54mm 40 pin IDC connector


    Product Details:

    Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable

    Double Row Fc-40 2.54mm 40 Pin Female Idc With 2651 28awg 1.27mm Flat Rainbow Cable

    Our Company:


    1. RY Electronics has over 10 years of experience designing and manufacturing custom cable assemblies and antennas in large or small volumes depending on your needs.

    2. Our manufacturing facilities can build just about many types of custom cable assembly(LVDS cable/Flat cable/RF cable/wire harness) as well as GPS/WIFI/ISM/GSM/3G/4G antenna and RF connectors.

    Our advantages:


    1. Quality control:most of products have UL CE ROHS, certificate. ISO9001:2008.

    2. Low MOQ:5pcs/10pcs/20pcs/50pcs,depends on different items.

    3. Fast Delivery Time :2~15 days, On-Time Delivery.

    4. Good After-Sales Service: we could offer technical support or return service in short time.

    5. 1 Year Warranty.

    6. OEM/ODM service.


    FAQ:
    1. When can I ?
    We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

    2. How can I get a sample to check your quality?
    After price confirmation, you can require for samples to check our quality.



    3. How long can I expect to get the sample?
    After you pay for the sample charge and we confirm the drawing with each other, the samples will be ready for 3-5 days. The samples will be sent to you via express and arrive in 3-5 days. You can use your own express account or prepay us if you do not have an account.


    4. What kind of files do you accept for printing?

    PDF, Core Draw, high resolution JPG



    5. What about the lead time for mass production?
    Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to15 days. Generally speaking, all of the goods can be reach your address within 4 weeks.

    6. What is your terms of delivery?
    We are accept EXW, FOB, CIF, etc.
