Place of Origin:
China
Brand Name:
RY
Certification:
rohs
Model Number:
RY-CAT6-RJ45
Contact Us
Video
| Specification | |
| Cable Spec | CAT6 32AWG 4pairs+AEB |
| Cable Length | 6ft, 10ft, 15ft, 25ft, 50ft, (Custom Length available) |
| Color | Black, Beige ,Blue(Custom Color available) |
| Diameter | OD:1.9*7.0mm |
| Wire Gauge | 32AWG,30AWG |
| Conductor | bare copper(BC),Tin plated copper(TC)(optional) |
| Certificate | RoHS,UL,CE,FCC |
| Plug mould | PVC molding, plastic shell , metal shell |
| Connector | gold-plated |
| Electrical Properties | |
| Quality Control | 100% open & short test |
| Voltage | DC300V 5M ohm/10ms |
| Insulation Resistance | 10M min |
| Contact Resistance | 2 ohm max |
| Working Temperature | -25C-80C |
| Data transfer rate | 10.2Gbps Max |
| Differential Impedance | 100±10Ω(TDR) |
| Complies with | TIA/EIA 568B standard |
Durable is a good wire, the outside is made of high quality environmental protection PVC material, with a certain wear resistance, anti-oil, can improve the service life of the wire, the line body is soft, and there are a variety of colors to choose from, gorgeous colors, rich life, from the beginning of the mountains! Round thread can be used everyday, flat thread can easily slip through the door, no need to worry about making holes in the wall!
Cat6 network cables have passed the test of FLUKE instrument in the United States, and the RJ network cable interface is fully compatible. It has the characteristics of long transmission distance, small transmission loss, wear resistance and pressure resistance, and is widely used in the field of high-speed local area network cabling. It supports gigabit Ethernet very well and realizes the transmission distance of 100M. As a result, six types of cabling systems are widely used for cabling subserver rooms, as well as horizontal cabling that retains the ability to upgrade to Gigabit Ethernet.
