Place of Origin:
China
Brand Name:
RY
Certification:
rohs
Model Number:
RY-CAT7-RJ45-22-1
Contact Us
Video
| Specification | |
| Cable Spec | CAT7 32AWG 4pairs+AEB |
| Cable Length | 6ft, 10ft, 15ft, 25ft, 50ft, (Custom Length available) |
| Color | Black, Beige ,Blue(Custom Color available) |
| Diameter | OD:1.9*7.0mm |
| Wire Gauge | 32AWG,30AWG |
| Conductor | bare copper(BC),Tin plated copper(TC)(optional) |
| Certificate | RoHS,UL,CE,FCC |
| Plug mould | PVC molding, plastic shell , metal shell |
| Connector | gold-plated |
| Electrical Properties | |
| Quality Control | 100% open & short test |
| Voltage | DC300V 5M ohm/10ms |
| Insulation Resistance | 10M min |
| Contact Resistance | 2 ohm max |
| Working Temperature | -25C-80C |
| Data transfer rate | 10.2Gbps Max |
| Differential Impedance | 100±10Ω(TDR) |
| Complies with | TIA/EIA 568B standard |
Twisted pair is the latest in ISO Class 7 /F standards. Instead of being an unshielded twisted pair, CAT 7 is a shielded twisted pair, with each pair having a shielding layer and four pairs combined together with a common large shielding layer. Physically, the additional shielding gives the seven types of wires a larger wire diameter. From the application point of view, this feature makes CAT 7 seven types of network cable mainly used in ten-megabit Ethernet technology.
The CAT 7 Class 7 cable can provide a combined attenuation-to-crostalk ratio of at least 500MHz and an overall bandwidth of 600MHz, more than double the Class 6 cable and Super Class 6 cable, with a transmission rate of 10Gbps for Class 7 cable.
